Easily discover, connect and control BACnet devices over both IP and serial networks with IOTech’s high performance BACnet device connector
What is BACnet?
- BACnet (Building Automation and Control Network) is an open communications protocol used for the standard communication between control systems and devices, particularly in the Building Automation Industry
- BACnet is prevalent in COTS devices relating to heating, ventilation, lighting, air-conditioning control (HVAC), access control and fire detection systems
- BACnet is a rich protocol that defines specific services and objects used to communicate between the devices. It also defines how data is delivered on the network with standards for:
- BACnet IP - communication over Ethernet
- BACnet MS/TP (Master slave / token passing) which uses RS485 serial connections
- Compared to proprietary approaches, BACnet controllers and devices from different suppliers and manufacturers are able to communicate with generally little integration effort
IOTech's BACnet device connector supports both BACnet IP and BACnet MS/TP and provides advanced functionality including automatic device discovery and performance optimizations such as reading and writing multiple values in single BACnet commands
IOTech's BACnet device connector implements the following key features:
- Support for both BACnet IP and BACnet MSTP devices
- Automatic discovery, profile generation and onboarding of BACnet devices including controls for selective filtering of objects and data points
- Reading single BACnet values via the ReadProperty operation
- Writing single BACnet values via the WriteProperty operation
- Reading multiple BACnet values via the ReadMultipleProperty operation
- Writing multiple BACnet values via the WriteMultipleProperty operation
- Change of Value (COV) subscriptions
- Support for Boolean, Unsigned Int, Signed Int, Real, Double, Character String, Octet String, Bit String, BACnetObjectIdentifier, Enumerated, Date and Time data types
- Support for reading BACnet arrays
- Support for BACnet priority levels
- Support for BACnet/IP Broadcast Management Device (BBMD) communication between IP subnets
